P8 Banner Led Stadium Advertising Boards Full Color For Football / Basketball Court

P8 Banner Led Stadium Advertising Boards Full Color For Football / Basketball Court

Product Details:
Place of Origin: China
Brand Name: Vios
Certification: UL EMC CE ROHS Fcc ISO90001 ETL SGS SAA
Model Number: P8
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: please email us to get new price
Packaging Details: Carton box / Flight case / Wooden box
Delivery Time: 7-15days
Payment Terms: L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA
Supply Ability: 5000 Square/one month

Product Detail

The P8 Stadium LED Screen from Leyarled is a 960×960 mm stadium LED screen for scoreboards, replays and sponsor loops, built around a P8 screen that resolves 14,400 pixels per cabinet. Cabinets are sealed to IP65, run 6,500 cd/m² with 1920-3840 Hz refresh, and ship with the layout drawing, control configuration and spare modules already matched to the order.

P8 Stadium LED Screen 960x960mm stadium LED screen - Leyarled

P8 Stadium LED Screen: key features

  • 1920-3840 Hz refresh rate – no scan lines when a phone or broadcast camera pans across the screen.
  • About 33.2 kg per cabinet, 280 W/m² average draw – power and structure can be sized from these two numbers before the layout is final.
  • Kinglight LEDs on a die-cast aluminium cabinet – both parts are held as spares in Shenzhen for five years after the order.
  • Factory calibration before packing – brightness and colour bins are matched across cabinets so a 40 m² wall reads as one surface.

P8 Stadium LED Screen technical specification

Parameter Value
Pixel pitch P8 (8 mm)
Module size 320×160 mm
Module count 18 per cabinet
Cabinet size 960×960 mm
Resolution per cabinet 120×120 px (14,400)
Brightness 6,500 cd/m² (auto dimming)
Refresh rate 1920-3840 Hz
Scan mode constant current, high scan
Protection IP65
LED lamp Kinglight
Cabinet material die-cast aluminium
Cabinet weight about 33.2 kg (36 kg/m²)
Average power about 280 W/m²
Viewing distance 12 m minimum, 24 m comfortable
Lifespan 100,000 hours
Warranty 3 years

The table shows the standard build for this P8 Stadium LED Screen. Cabinet size, brightness and control system can be changed per project; the final datasheet is issued with the PI before production. Cabinets are tested against IEC 60068 for temperature, humidity and vibration.

How the numbers work on a real wall

The arithmetic behind this P8 Stadium LED Screen is simple enough to check before you order: 960÷8 = 120 pixels across each cabinet and 960÷8 = 120 down, so six cabinets in a row resolve 720 pixels at 5.76 m wide. Viewing distance follows the pitch – 12 m before the pixel structure disappears, 24 m before body copy reads cleanly. Because the cabinet divides into 18 standard 320×160 mm modules, a replacement module is never a custom order.

Product details

TBC Stadium Perimeter LED Screens are widely used for brand logo message advertising, live broadcasting in basketball, soccer, football, baseball stadium.

P8 Stadium LED Screen 960x960mm stadium LED screen - Leyarled

Where the P8 Stadium LED Screen is used

  • Sports halls – score and sponsor loops for indoor leagues.
  • Cricket and athletics venues – large-format scoring with high-brightness output.
  • Public viewing areas – temporary big-screen installations for tournaments.
  • Football stadiums – scoreboards and replays above the stands or behind the goals.

Installation and service access

Large stadium screens are usually suspended from a steel truss or mounted on a rear support frame. We supply a load calculation with the structure drawing so the venue engineer can approve the anchors before shipping.

For outdoor venues we add a lightning-protection and grounding kit to the bom by default. 3-year warranty on modules, power supplies and receiving cards; spare parts held in Shenzhen for five years after the order.

P8 Stadium LED Screen: frequently asked questions

Can I see this LED display running before I order?

Yes. We send a video of the exact cabinet type under a white and a grey test pattern, plus a phone camera pan, so you can judge scan lines and uniformity before the deposit.

What does the 3-year warranty cover?

LED modules, drivers, receiving cards and cabinet hardware, with free replacement of failed units in the first 3 years and chargeable spares held for five.

Can you put our brand on the P8 Stadium LED Screen?

Silkscreen on the 960×960 mm cabinet, a branded carton and a custom manual are included from 50 m²; below that we print labels only, so the MOQ stays at one square metre.

Will this P8 Stadium LED Screen survive a coastal or high-humidity site?

Yes, with the coastal option: epoxy coating on the cabinet, stainless screws, conformal-coated driver boards. Humidity above 85% year-round is the case where that option pays for itself.

Request a price for the P8 Stadium LED Screen

Send the screen size, viewing distance and project country, and our engineers return a layout drawing, a resolution map and a factory price within 24 hours. Similar models are listed under Stadium LED Display range, and you can compare p10 stadium led screen, p3 stadium led screen. Direct contact goes through the contact page. When you compare quotations, ask every supplier for the module brand, the power-supply brand and the spare ratio in the carton – that is where prices usually differ.
