Detailed Product Description
Pixel: | 3.91mm | Color: | Full Color |
LEDs: | SMD 3in1 | Scan: | 1/16 Scan |
Module Size: | 250mmx250mm | ||
High Light: | led rental screen,hire led screen |
P3.91 Outdoor stage full color rental LED screen
Product features:
1)The thickness of the panel is only 80mm, the weight of the 500x500mm panel is only 7kg, and the 500x100mm panel is only 14kg, and adults can easily lift it with one hand.
2)Installing or disassembling in just 8 seconds using a quick locking system.
3)The refresh rate is over 1900Hz/s, and the LED screen displays no stripes, which can be used for camera shooting.
4)The new structure design allows for a variety of installations and can meet the requirements of suspension and stacking.
Product specification:
Item |
Value |
Brightness(nits) |
4200 |
Color temperature(deg.k) |
3200 ~ 9300 |
Viewing angle – Horizontal(deg.) |
140(+70/-70) |
Viewing angle – Vertical(deg.) |
140(+70/-70) |
Cabinet weight(kg) |
9 |
Cabinet width(mm) |
500 |
Cabinet height(mm) |
500 |
Cabinet depth(mm) |
80 |
Cabinet area (sq. m.) |
0.25 |
Cabinet material |
Aluminum |
Aspect ratio |
1:1 |
Ingress protection (Front/Rear) |
IP65/IP43 |
Operating temperature range(deg. C) |
– 20 to 50 |
Operating humidity range(HR) |
10% to 90% |
Pixel type and configuration(R/G/B) |
SMD 3in1 |
Pixel pitch(mm) |
3.91 |
Pixel matrix per cabinet |
128×128 |
Pixels per cabinet |
16384 |
Lines per meter |
256 |
Pixels per sq. meter |
65536 |
LEDs per sq. meter |
65536 |
Recommended minimum viewing distance(m) |
4 |
Colours |
281trillion |
Gray scale(Levels) |
65536 levels per colour |
Brightness control(Levels) |
100 |
Digital processing(bit) |
16 |
Frame rate(Hertz) |
60 |
Display refresh rate(Hertz) |
1440 |
Input voltage(VAC) |
110/240 |
Input power frequency(Hertz) |
50/60 |
Input power (max/avg)(Watts per sq.m) |
800/280 |
MTBF(Hours) |
≥10000 |
Lifetime (50%Brightness) (Hours) |
≥100000 |
Module brightness uniformity |
<5% |
Blind spot rate |
<0.0001 |
Earth leakage current(mA) |
<2 |
Red wavelength(nm) |
623 |
Green wavelength(nm) |
525 |
Blue wavelength(nm) |
470 |
Panel input format (with video processor) |
VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV |
Data interconnection |
CAT6 cable/Fiber |
Operating system |
Windows(XP/Vista/7/8/10) |
Control distance |
Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. |
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 5 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
tag: P3.91 Outdoor LED screen , stage full color LED screen , rental LED screen
