P2.5 SMD Full Color LED Curtain Wall Display , LED Stage Curtain Screen High Resolution

P2.5 SMD Full Color LED Curtain Wall Display , LED Stage Curtain Screen High Resolution

Product Details:
Place of Origin: China(Mainland)
Brand Name: Vios
Certification: CE ,RoHS, FCC.CCC,SAA ,TUV ,UL
Model Number: P2.5
Payment & Shipping Terms:
Minimum Order Quantity: customized
Price: Negotiations
Packaging Details: Wooden and flight case ,it’s up to you.
Delivery Time: 7-10 working days after payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqs/month
Inquiry

Product description

Brand Name: Curtain LED Display Material Cabinet: Aluminum
Pitch: 2.5mm Module Size: 160*160mm
Pixel Density: 160000dots/sq Control System: LSN
Working Voltage: DC5V Brightness: ≥1500cd/sq
Warranty: 3-5years Indoor Options: P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6…
Certificate: CE ,RoHS, FCC.CCC,SAA ,TUV ,UL
High Light: rgb led curtain, led curtain screen



SMD Full Color LED Curtain Wall Display , LED Stage Curtain Screen P2.5 Indoor Statium With High Resolution





Info about company:



Shenzhen ShiChuangXin Ke Electronic Co.,Ltd has been specialized in LED field since 2005. We are a leading manufacturer and provider of technical solution of full color indoor an outdoor ledisplay,rental LED display, led modules where in Shenzhen ctiy,Guangdong province,China.





Quick Detail:

1, High resolution at 160000pixels/㎡;
2, LED Chips: Epistar high brightness;
3, High brightness up to 7000cd/㎡;
4, Power Supply: Meanwell;G-erngy ,chuanglian LED driver
5, Control System: Linsn,Nova etc.

Description:

1, P2.5 SMD LED display is high resolution for indoor LED screens use;
2, Large viewing angle at 140 degree horizontal and vertical;
3, Eletronic digital sign P2.5 is being used more and more, as LED screens trend is high resolution.
4, Clear and vivid advertising image and video;
5, High contrast ratio at 1000:1 to present true and natural color LED screens;

Applications:



Airport Full Color Indoor LED displays advertising

Train station Indoor Full Color LED Displays

Entertainment Bar Indoor Full Color LED Screen

Stadium Indoor Full Color LED Display

Museum Full Color Indoor LED display

Car exhibition LED display

Conference room Indoor Full Color LED Video Display

Shopping Mall Indoor Full Color LED display





Specifications :



Indoor SMD P2.5
Resolution/mm 2.5
Pixel configuration 1R1G1B
Pixel density/pixels/m² 160000/square meter
Module resolution 64×64
Module size/mm 160x160MM
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >1500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/32 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%





20200516092011_27016



Our Results:

20200516091933_32874





RFQ:

20200516092357_96911

Welcome to visit our website and inquire us!!!



Contact Person: HERO
Business Developer.
Email : liujinmiao@wehchi.com
Skype: liujinmiaohero@outlook.com
Wechat & Whatsapp & Mobile : +86 18923432534
Linkedin : :https://www.linkedin.com/feed/
FaceBook :https://www.facebook.com/profile.php?id=100066426288768
Shenzhen Vios Electronic Technoloy Co., Ltd
“customer first, integrity first, innovation, and strive for perfection”
Add : Room C411 Floor 4, C Building, Sijixingcheng, Zhenming Road No.161, Gongming Town, Guangming new district, Shenzhen City, China
Tel:+86-0755-86902546
