Product Detail
The P1.25 Indoor LED Display Module is a P1.25 module of 320x160mm, built with SMD1010 LEDs and 32,768 pixels per panel. Leyarled supplies it as a spare for an installed wall or as the building block for a custom size, and it is calibrated to the same bin as the cabinets it ships with so a replacement does not show as a bright patch.


P1.25 Indoor LED Display Module: key features
- 320x160mm module, P1.25 – 256×128 pixels, about 640,000 dots per square metre.
- SMD1010 LED package – the same bin and batch as the cabinets in the order, which is what keeps colour uniform.
- Front or rear service – magnetic front removal on most cabinets, so a module swap needs no rear access.
- Spare-part friendly – one module covers several cabinet sizes, so stock stays small.
P1.25 Indoor LED Display Module specification
| Parameter | Value |
|---|---|
| Pixel pitch | P1.25 |
| Module size | 320x160mm |
| Resolution | 256×128 px (32,768) |
| Pixel density | 640,000 dots/m² |
| LED package | SMD1010 |
| Scan mode | constant current, high scan |
| Brightness | 5,000-6,000 cd/m² outdoor, 800-1,200 indoor |
| Lifespan | 100,000 hours |
| Warranty | 2 years |
Replacing a module without changing the wall
Match three things before ordering a spare: pitch, module size and connector. A 320x160mm module at P1.25 fits any cabinet in the same family, but a module from a different batch can read warmer or cooler, so ask for the bin code on the label. Keep 2-3% of the module count as spares; for a 469 module wall that is a handful of panels, and a swap takes minutes with a suction tool.
Building a custom size from modules
Modules are how non-standard walls are made: a 320x160mm grid cuts to any size in 320 mm steps horizontally and 160 mm vertically, so a wall can follow a building instead of the other way round. Send the opening size and we return the module count, resolution and power estimate.
Buying notes
Module prices vary mostly on the LED package and the PCB, not on the plastic mask. Ask which chip brand and bin are used, how many layers the PCB has, and whether the module is tested for colour before packing. A cheaper module with an unmatched bin will show as a patch on a wall within a year, and replacing it again costs more than the difference.
What ships with the P1.25 Indoor LED Display Module
Modules ship in foam-lined cartons with anti-static bags, a suction tool for removal and a wiring diagram. Orders over 50 pieces are palletised and can be mixed with power supplies and receiving cards so a spare kit arrives in one shipment.
P1.25 Indoor LED Display Module: frequently asked questions
Is this P1.25 Indoor LED Display Module compatible with my existing cabinet?
Check pitch, module size and connector. If all three match, it drops in. Send a photo of the module label and the cabinet rear and we confirm before you order.
What is the minimum order for a P1.25 Indoor LED Display Module?
One piece for a spare, ten pieces for a small repair batch, and full-carton pricing from 50 pieces.
How is a P1.25 Indoor LED Display Module shipped?
Foam-lined carton with anti-static bag, 20-40 modules per carton depending on size, and air freight for urgent spares.
Request a price for the P1.25 Indoor LED Display Module
Send the model number, the wall or frame it has to work with and the project country; our engineers confirm compatibility and return a factory price within 24 hours. Related items are listed under Fixed LED Display range and p4 indoor led billboard, led display screen, and direct contact goes through the contact page. Spare-part orders ship with a serial list so the part can be matched to the unit it replaces.
