Leyarled builds this P2 Indoor Fine Pitch LED Display in Shenzhen on a 250×250 mm die-cast aluminium cabinet: P2 Kinglight LEDs, 15,625 pixels per panel, 1,000 cd/m² and IP65. It is the configuration most boardroom and studio buyers settle on when they need conference rooms, studios and control rooms to run daily without a local engineer.
P2 Indoor Fine Pitch LED Display: key features
- Kinglight LEDs on a die-cast aluminium cabinet – the lamp and cabinet pairing is what decides colour consistency after three years.
- Factory calibration before packing – brightness and colour bins are matched across cabinets so a 40 m² wall reads as one surface.
- 15,625 pixels per cabinet (P2, 250×250 mm) – a 4×3 wall lands at 500×375 (0.19 MP) without any custom cutting.
- NovaStar and ColorLight compatible control – the control path stays one card, one processor, one content source.
P2 Indoor Fine Pitch LED Display technical specification
| Parameter | Value |
|---|---|
| Pixel pitch | P2 (2 mm) |
| Module size | 250×250 mm |
| Module count | 1 per cabinet |
| Cabinet size | 250×250 mm |
| Resolution per cabinet | 125×125 px (15,625) |
| Brightness | 1,000 cd/m² (auto dimming) |
| Refresh rate | 1920-3840 Hz |
| Scan mode | constant current, high scan |
| Protection | IP65 |
| LED lamp | Kinglight |
| Cabinet material | die-cast aluminium |
| Cabinet weight | about 4 kg (25 kg/m²) |
| Average power | about 192 W/m² |
| Viewing distance | 3 m minimum, 6 m comfortable |
| Lifespan | 100,000 hours |
| Warranty | 3 years |
The table shows the standard build for this P2 Indoor Fine Pitch LED Display. Cabinet size, brightness and control system can be changed per project; the final datasheet is issued with the PI before production. Cabinets are tested against IEC 60068 for temperature, humidity and vibration.
How the numbers work on a real wall
To size this P2 Indoor Fine Pitch LED Display, start from whole cabinets: a 4×3 build gives a 1.0×0.75 m screen, 500×375 pixels (0.19 MP), about 3 kg of cabinet and an average load near 100 W. Add one row and the same cabinet family gives 1.0 m height with no new tooling, which is why projects usually fix the wall size first and the pitch second.
Product details
Steady and reliable system:with strong anti-interference ability and long service life that can continually work for over 24 hours, and it’s easy to operate the system.
High refresh rate, high brightness and high contrast which make the screen without any delay and smear phenomenon under directly sunlight.
Where the P2 Indoor Fine Pitch LED Display is used
- Boardrooms and meeting rooms – 16:9 walls sized for video conferencing.
- Showrooms – close-viewing product walls.
- Broadcast studios – camera-facing backdrops with high refresh and no scan lines.
- Command centres – multi-source walls running around the clock.
Installation and service access
Fine pitch cabinets are installed on a levelling frame with a tolerance under 0.3 mm across the wall, because any seam is visible at two metres. We ship a levelling kit and an alignment procedure with every order.
For 16:9 rooms, 600×337.5 mm cabinets build a 2k or 4k wall without custom cutting. 3-year warranty on modules, power supplies and receiving cards; spare parts held in Shenzhen for five years after the order.
P2 Indoor Fine Pitch LED Display: frequently asked questions
How many spare modules should I keep?
Budget 2-3% of modules plus one power supply per 20 cabinets. A spare module is a five-minute swap, so the stock is insurance against downtime, not a repair plan.
Can you build this P2 Indoor Fine Pitch LED Display in a custom size?
Any size built from 250×250 mm cabinets, plus half-cabinet trims where a wall cannot take a full module. You get a drawing with the pixel count and centre-to-centre dimensions to check against the building.
Do you supply the steel structure and drawings?
Structure drawings and load calculations are included with the order; the steel itself is usually fabricated locally to save freight. We review the workshop drawing before it is cut.
How is the P2 Indoor Fine Pitch LED Display shipped, and what spare parts come with it?
Export packing is plywood with foam, and each case is labelled by cabinet position so installation follows the drawing. Spares: 2-3% modules, 1% power supplies, 1% receiving cards.
Request a price for the P2 Indoor Fine Pitch LED Display
Send the screen size, viewing distance and project country, and our engineers return a layout drawing, a resolution map and a factory price within 24 hours. Similar models are listed under Indoor Full Color LED Display range, and you can compare p4.81 indoor led display screen, p2 indoor led display screen. Direct contact goes through the contact page. When you compare quotations, ask every supplier for the module brand, the power-supply brand and the spare ratio in the carton – that is where prices usually differ.
