Epistar 1/13 Scan HD 52*52 P4.81 Indoor Full Color LED Display

Product Details:
Place of Origin: China(Mainland)
Brand Name: Vios
Certification: CE,RoHS,FCC,CCC,SAA,TUV,UL
Model Number: P4.81
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiations
Packaging Details: Wooden and flight cases,it’s up to you.
Delivery Time: 7-10 working days after payment
Payment Terms: T/T, Western Union
Supply Ability: 5000sqs/month

Product description

Pitch: 4.81mm Scan Mode: 1/13
Control Mode: Synchronous By DVI Module Size: 250*250mm
Cabinet Material: Aluminum Resolution: 52*52
Warranty: 3-5 Years Indoor Options: P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P8,P10…
High Light: 1/13 rgb led display, P4.81 indoor rental led display



P4.81 Full color indoor led display led screen panel led video wall with Resolution 52*52 HD Epistar 1/13 Scan





Quick Browse:



1. The high definition and low gray scale.

2. Easy move for rental with lightweight.

3. Strong power supply can be used for a long time.

4. Control system for LSN,Synchronous display with control PC by DVI.

5. High resolution that the image can be clearly appeared.





Product description:



Indoor P4.81 LED Display
Resolution/mm 4.81
Pixel configuration 1R1G1B
Pixel density/pixels/m² 43222/square meter
Module resolution 52x52mm
Module size/mm 250*250mm
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/13 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%





FAQ:



Q1:What pixel pitch should I choose on my display?



A:Using the PX screen, it is determined mainly by the viewing distance, the size of the display screen, the
desired effect and the customer budget.



Q2: To order a display ,What kind of information do I have to offer you?



A:You should provide width/height of the display, the main use, the viewing distance, the scene photos, special requirements,then I can provide you with a detailed list of quotations.



Q3:How to install?

A:Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram,
free remote debugging. We can also send our engineers to the site to guide the installation if needed.



Q4:What about your quality?

A:The quality of our display is excellent. We use the materials of high quality suppliers in the world,
strictly control the production process, and pass the multiple quality inspection to ensure that every
product is qualified.



Q5:What about the warranty?



A:3-5 years warranty



Q6:What about the lead time?

A:Orders less than 50 square meter display, lead time is 15 working days.
