Product Detail
The P2 Indoor LED Display Screen is a factory-direct indoor LED display with a 640×480 mm cabinet that weighs about 7.4 kg and draws roughly 217 W/m² on average. Screen resolution works out at 320×240 per cabinet, so one panel already covers 76,800 pixels of reception walls, retail and wayfinding.
P2 Indoor LED Display Screen: key features
- IP31 sealed cabinet with pressure valve – the breathable valve equalises pressure so gaskets are not stressed.
- 1,000 cd/m² with automatic brightness control – the sensor trims output after dusk instead of running flat out.
- 8 modules per cabinet, 192×192 mm each – module size is standard, so replacements are never a custom order.
- Front-service magnetic modules – maintenance does not need scaffold access behind the screen.
P2 Indoor LED Display Screen technical specification
| Parameter | Value |
|---|---|
| Pixel pitch | P2 (2 mm) |
| Module size | 192×192 mm |
| Module count | 8 per cabinet |
| Cabinet size | 640×480 mm |
| Resolution per cabinet | 320×240 px (76,800) |
| Brightness | 1,000 cd/m² (auto dimming) |
| Refresh rate | 1920-3840 Hz |
| Scan mode | constant current, high scan |
| Protection | IP31 |
| LED lamp | Kinglight |
| Viewing angle | 160 / 160° |
| Cabinet material | die-cast aluminium |
| Cabinet weight | about 7.4 kg (24 kg/m²) |
| Average power | about 217 W/m² |
| Viewing distance | 3 m minimum, 6 m comfortable |
| Lifespan | 100,000 hours |
| Warranty | 3 years |
The table shows the standard build for this P2 Indoor LED Display Screen. Cabinet size, brightness and control system can be changed per project; the final datasheet is issued with the PI before production. Cabinets are tested against IEC 60068 for temperature, humidity and vibration.
How the numbers work on a real wall
To size this P2 Indoor LED Display Screen, start from whole cabinets: a 4×3 build gives a 2.56×1.44 m screen, 1280×720 pixels (0.92 MP), about 27 kg of cabinet and an average load near 800 W. Add one row and the same cabinet family gives 1.92 m height with no new tooling, which is why projects usually fix the wall size first and the pitch second.
Product details
We seriously practice 24 hours led module testing time and 72 hours led display aging time.Before shipping and within the warranty time,our team will track the goods situation to satisfy all your request.
Standard processing technology to ensure that each row and each column tube at the same level, ensure the stability of the clear picture.
Where the P2 Indoor LED Display Screen is used
- Conference and hotel lobbies – welcome screens and event schedules.
- Corporate offices – reception media walls and internal comms.
- Education – lecture theatres and campus wayfinding.
- Retail stores – promotional walls and window displays.
Installation and service access
Indoor screens are typically wall-mounted on a bracket or recessed into a joinery frame. Because the viewing distance is short, we set brightness to 600-1200 nits and use a low-brightness calibration so the wall does not glare in a dim room.
A magnetic front-service module means the screen can sit flush against a finished wall. 3-year warranty on modules, power supplies and receiving cards; spare parts held in Shenzhen for five years after the order.
P2 Indoor LED Display Screen: frequently asked questions
What does the 3-year warranty cover?
LED modules, drivers, receiving cards and cabinet hardware, with free replacement of failed units in the first 3 years and chargeable spares held for five.
Can you put our brand on the P2 Indoor LED Display Screen?
Yes. OEM branding covers the cabinet badge, the packing label and the manual, and the control software can be locked to your logo on request.
Will this P2 Indoor LED Display Screen survive a coastal or high-humidity site?
Yes, with the coastal option: epoxy coating on the cabinet, stainless screws, conformal-coated driver boards. Humidity above 85% year-round is the case where that option pays for itself.
What is the lead time for a P2 Indoor LED Display Screen order?
Standard cabinets ship in 7-12 working days after the deposit clears; a full project with structure, control and commissioning takes 15-20 days. Custom cabinet sizes or curved frames add 3-5 days. We send a production photo set before the goods leave Shenzhen.
Request a price for the P2 Indoor LED Display Screen
Send the screen size, viewing distance and project country, and our engineers return a layout drawing, a resolution map and a factory price within 24 hours. Similar models are listed under Indoor Full Color LED Display range, and you can compare p4 indoor led video wall, p4 indoor smd led screen. Direct contact goes through the contact page. When you compare quotations, ask every supplier for the module brand, the power-supply brand and the spare ratio in the carton – that is where prices usually differ.
