For reception walls, retail and wayfinding, the P2.5 Indoor LED Display Screen is the model we quote most often: 512×512 mm cabinets, P2.5 pitch, 1,000 cd/m², IP65 sealing and 1920-3840 Hz refresh. Factory-direct from our Shenzhen line, 7-12 working days for standard cabinets, spare modules in every carton.
P2.5 Indoor LED Display Screen: key features
- 42,025 pixels per cabinet (P2.5, 512×512 mm) – a 4×3 wall lands at 820×615 (0.5 MP) without any custom cutting.
- NovaStar and ColorLight compatible control – the control path stays one card, one processor, one content source.
- IP65 sealed cabinet with pressure valve – rain, dust and pressure swings do not pull moisture into the module cavity.
- 1,000 cd/m² with automatic brightness control – daylight legible at 8 m, dimmed at night to stay inside local light rules.
P2.5 Indoor LED Display Screen technical specification
| Parameter | Value |
|---|---|
| Pixel pitch | P2.5 (2.5 mm) |
| Module size | 256×128 mm |
| Module count | 8 per cabinet |
| Cabinet size | 512×512 mm |
| Resolution per cabinet | 205×205 px (42,025) |
| Brightness | 1,000 cd/m² (auto dimming) |
| Refresh rate | 1920-3840 Hz |
| Scan mode | 1/16 |
| Protection | IP65 |
| LED lamp | Kinglight |
| Cabinet material | die-cast aluminium |
| Cabinet weight | about 6.3 kg (24 kg/m²) |
| Average power | about 217 W/m² |
| Viewing distance | 3.8 m minimum, 8 m comfortable |
| Lifespan | 100,000 hours |
| Warranty | 3 years |
The table shows the standard build for this P2.5 Indoor LED Display Screen. Cabinet size, brightness and control system can be changed per project; the final datasheet is issued with the PI before production. Cabinets are tested against IEC 60068 for temperature, humidity and vibration.
How the numbers work on a real wall
To size this P2.5 Indoor LED Display Screen, start from whole cabinets: a 4×3 build gives a 2.05×1.54 m screen, 820×615 pixels (0.5 MP), about 20 kg of cabinet and an average load near 700 W. Add one row and the same cabinet family gives 2.05 m height with no new tooling, which is why projects usually fix the wall size first and the pitch second.
Product details
ShenzhenVios Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.
Where the P2.5 Indoor LED Display Screen is used
- Education – lecture theatres and campus wayfinding.
- Retail stores – promotional walls and window displays.
- Conference and hotel lobbies – welcome screens and event schedules.
- Corporate offices – reception media walls and internal comms.
Installation and service access
Indoor screens are typically wall-mounted on a bracket or recessed into a joinery frame. Because the viewing distance is short, we set brightness to 600-1200 nits and use a low-brightness calibration so the wall does not glare in a dim room.
A magnetic front-service module means the screen can sit flush against a finished wall. 3-year warranty on modules, power supplies and receiving cards; spare parts held in Shenzhen for five years after the order.
P2.5 Indoor LED Display Screen: frequently asked questions
Do you supply the steel structure and drawings?
Yes. We issue the cabinet layout, a steel-frame drawing, wind-load notes and the power distribution plan, so a local fabricator can build the structure to our dimensions.
How is the P2.5 Indoor LED Display Screen shipped, and what spare parts come with it?
Export packing is plywood with foam, and each case is labelled by cabinet position so installation follows the drawing. Spares: 2-3% modules, 1% power supplies, 1% receiving cards.
Is the P2.5 Indoor LED Display Screen CE and RoHS certified?
CE, RoHS and FCC reports are issued against the BOM of this P2.5 cabinet, together with IEC 60068 climate and vibration reports. Certificates travel with the shipping documents.
What brightness do I need for this P2.5 Indoor LED Display Screen?
This model is set to 1,000 cd/m². For a north-facing wall or an indoor position, 800-1,500 cd/m² is enough; direct sun needs 5,000 cd/m² and above. Keep 3x headroom over ambient light and let the auto-dimming sensor handle the rest.
Request a price for the P2.5 Indoor LED Display Screen
Send the screen size, viewing distance and project country, and our engineers return a layout drawing, a resolution map and a factory price within 24 hours. Similar models are listed under Indoor Full Color LED Display range, and you can compare p1.8 indoor led display screen, p6 indoor smd led screen. Direct contact goes through the contact page. When you compare quotations, ask every supplier for the module brand, the power-supply brand and the spare ratio in the carton – that is where prices usually differ.
