outdoor LED Screen Module 1/8 scanning outdoor P4 SMD LED Display Module 256*128mm

Product Details:
Place of Origin:
China
Brand Name:
Vios
Certification:
CE/ROHS/FCC/ISO/UL
Model Number:
P4

    Payment & Shipping Terms:
    Minimum Order Quantity:
    negotiation
    Price:
    negotiation
    Packaging Details:
    flight case, wooden case, carton, it is up to you.
    Delivery Time:
    7-10 working days after receive your payment
    Payment Terms:
    T/T or western Union
    Supply Ability:
    5000sqm per month
    Detailed Product Description:
    Product Name:
    Led Display Module
    Module Size(W * H):
    256mm*128mm
    Tube Chip Color:
    Full Color
    Pixel Pitch:
    4mm
    Module Qty:
    1pcs
    Resolution(W*H):
    64dots*32dots
    High Light:
    led screen module   .rgb led display module

    Outdoor P4 SMD LED Display Module 256*128mm , outdoor  LED Screen Module 1/8 scanning



    Shenzhen Vios Electronic Technoloy Co., Ltd promote the environment protection and energy saving with LED technology,we adopt the LED characterized with energy saving and envronmental friendliness as basic raw material.
    Now Vios offer :Rental LED Screen , Fixed Installation LED ScreenTransparent LED Curtain Screen,Dance Floor/Stair LED Screen,Flexible LED Screen,Front access LED Screen.and Perimeter LED Screen.
    Vios consider product quality as company life, we take serial reliable tests in each process from the initial production until finished product. The tests cover all important performances, including flatness, power consumption, brightness, color, shock resistance;IP rating and so on, TOPLED adopt the most strict quality control system to guarantee products with perfect quality
    The detailed parameter as follows.
    1,  Item Name
    P4 indoor SMD LED Display Module size 256*128mm 1/8 scanning
    2,  pixel tube:
       pixel pitch:4mm;  primary colors: pure red+pure green+pure blue ,
    color composing: 1R1G1B
    Density:3906dots/sq m;  smd3535
    3 , unit box
      module size:256mm×128mm;  Module resolution:64X32
    cabinet thickness:(cold-roll steel sheet)150mm+(maintain)600mm;
    4, whole screen:
    the optimum viewing angel :horizontal 110°, vertical 50°
    viewing distance:>15m;working temperature:-20°C~+45°C(-30°C ~+50°C  optional)    relative humidity:≤95%RH;   Drive IC ET6024
    5, operating voltage
    AC220V±10% or 110V±10% ,average consumption:500 W/sq m
    max consumption:≤650 W/ sq m
    6, main parameter
    1) driving mode: 1/8 scanning
    2) refreshing rate:≥400Hz/s
    3) frame frequency:≥60Hz/s
    4) gray scale/color:≥16.7Mcolors(Synchronized)
    5) manage gray:≥72bit
    6) brightness:≥1500cd/sq m
    7) color temperature condition:3500K~9500K,be adjustable
    8) adjusting style of brightness: hand movement/auto
    9) video signal: RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc. managing ability of signal:≥12bit.against Y revised curve: owns 3pcs above Y curve that can adjustable.
    10) average trouble-free time:≥5000hours
    11) evenness: between random adjacent pixel ≤0.5mm,module splicing space<1mm
    12) switch power loading:5V/40A
    13) display mode of computer:1024×768



    outdoor P4 SMD LED Display Module 256*128mm , outdoor LED Screen Module 1/8 scanning 0
    competitive Advantage:
    1. 5 years’ warranty with free repair service
    2. 24/7 Hours online Remote Support
    3. Solution and PCB design
    4. Free factory training
    5. On site installation instruction and regular inspection
    6, Small order accepted.
    Methods for Quality Assurance
    a. Aging
    1. 100% fully test
    Condition: 72 hours with 256 gray level
    b. Vibration Testing
    Condition: 3-5 min up and down in 5mm range
    outdoor P4 SMD LED Display Module 256*128mm , outdoor LED Screen Module 1/8 scanning 0
    competitive Advantage:
    1. 5 years’ warranty with free repair service
    2. 24/7 Hours online Remote Support
    3. Solution and PCB design
    4. Free factory training
    5. On site installation instruction and regular inspection
    6, Small order accepted.
    Methods for Quality Assurance
    a. Aging
    1. 100% fully test
    Condition: 72 hours with 256 gray level
    b. Vibration Testing
    Condition: 3-5 min up and down in 5mm range
