Brightness（nits） |
1000 |
Color temperature（deg.k） |
3200 ~ 9300 |
Viewing angle – Horizontal(deg.) |
140(+70/-70) |
Viewing angle – Vertical(deg.) |
140(+70/-70) |
Cabinet weight(kg) |
8 |
Cabinet width（mm） |
500 |
Cabinet height（mm） |
500 |
Cabinet depth（mm） |
80 |
Cabinet area（sq. m.） |
0.25 |
Cabinet material |
Aluminum |
Aspect ratio |
1:1 |
Ingress protection (Front/Rear) |
IP40/IP20 |
Operating temperature range(deg. C) |
0 to 40 |
Operating humidity range(HR) |
10％ to 90％ |
Pixel type and configuration(R/G/B) |
SMD 3in1 |
Pixel pitch（mm） |
3.91 |
Pixel matrix per cabinet |
128×128 |
Pixels per cabinet |
16384 |
Lines per meter |
256 |
Pixels per sq. meter |
65536 |
LEDs per sq. meter |
65536 |
Recommended minimum viewing distance（m） |
4 |
Colours |
281trillion |
Gray scale |
65536 levels per colour |
Brightness control(Levels) |
100 |
Digital processing（Bit） |
16 |
Frame rate（Hz） |
60 |
Display refresh rate（Hz） |
1440 |
Input voltage(bit) |
110/240 |
Input power frequency（Hz） |
50/60 |
Input power (max/avg)( Watts per sq.m) |
600/210 |
MTBF(Hours) |
≥10000 |
Lifetime (50%Brightness) (Hours) |
≥100000 |
Module brightness uniformity |
＜5％ |
Blind spot rate |
＜0.0001 |
Earth leakage current(mA) |
＜2 |
Red wavelength(nm) |
623 |
Green wavelength(nm) |
525 |
Blue wavelength(nm) |
470 |
Panel input format (with video processor) |
VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV |
Data interconnection |
CAT6 cable/Fiber |
Operating system |
Windows(XP/Vista/7/8/10) |
Control distance |
Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. |
