IP65 P10 LED Billboards , 32X16 high resolution led display 3 years warranty

Product Details:
Place of Origin: China
Brand Name: Vios
Certification: CE,ROHS ,FCC,UL
Model Number: P10
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm can be available
Price: negotiation
Packaging Details: the led display can be packaged with wooden box,paper box,flight case
Delivery Time: 5-8days
Payment Terms: L/C, T/T, Western Union

Product description

Refresh Rate: 2500HZ/S Pixel Density: 10000dots/sqm
Cabinet Size: 960mm X 960mm Display Color: 16.7million
Control System: 3G ,U-DISK ,wifi Power Supply: Series Connection
Control Method: Synchronization & Asynchronization LED Standard: Real Pixel(1R1G1B)
Protection Level: IP65
High Light: led digital billboards, led advertising billboards



IP65 P10 LED Billboards , 32X16 high resolution led display 5 years warranty



1.Automatic brightness control,super processing ability,strong colour restoration.

2.Support various interfaces and signal sources.

3.Advanced digital control technology, excellent effect.

4.High brightness,even in direct,full-on sunlight to ensure you attract more audience to get short ROI of your full color outdoor led display screen’s investment.

5.Antiseptic and durable, can be used outdoor in all weather.
LED module has easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display system.

With full aluminum alloy structure for light weight and waterproof advantages, outdoor LED display is an perfect external multimedia LED display system designed for changeable and adverse outdoor environment.



Feature of our products



Supported by advanced technology and professional team, come out world-class standard LED Display, featured with beautiful image, durable stability, low power consumption, wide viewing angle and nice protection rating. .Full automatic production to control our high quality, best color .Consistency and get better performance.
•Energy saving, low power consumption and long lifespan 100,000 hours (about 10 years).
•Shichuagnxinke guarantee that the products we provide are brand new, complete and unused.
•Good heat dissipation capability and high waterproof because of the unique design of vent fan
•shichuangxinke quality control throughout every process from materials-production- test-package-delivery



The outdoor P10 full color led display parameter as follows.



Product Name smd outdoor Full Color LED Display
Model No P10
Physical Pixel Pitch 10mm
Pixel Type Real Pixel(1R1G1B)
Red LED Lamp Optotech
Green&Blue LED Lamp Hcsemitek
Module Size 320mmx160mm
Cabinet Size 960mmx960mm
Module numbers per cabinet 3pcsx6pcs=18pcs
Cabinet numbers 1pcsx1pcs=1pcs
Module Resolution 96×96
Pixel Density 15625dots/sqm
Drive IC MBI5124
Best Viewing Distance 10m——200m
Drive Mode 1/4 scan



Wide application field :

Widely used in Advertising media,Concert, TV SHOW,Super mall, Entertainment,School,Government,Trading conversation,Commodity fair,Exhibition,Cinema,News conferences, Meeting room,Airport,Hotel,Station Hall and other Public Places.



Q: What are the differences between the outdoor ,indoor, semi-outdoor LED display ?
A1: Brightness: the brightness of indoor LED displays are much less than the outdoor and the semi-outdoor LED display. The brightness Of outdoor LED display and the semi-outdoor LED display are closed.
A2: Waterproof level: indoor and semi-outdoor LED display are not waterproof.

Q: What is the DIP? What is the SMD?
A1: DIP is a package technology which make the LED get through the PCB and then use the tin welding .
A2: SMD is a package technology which weld the LED on the surface of PCB .

Q: What is the difference between the SMD and the DIP?
A1: Brightness: The DIP modules are brighter than the SMD
A2: Viewing angle: The SMD modules has a big viewing angle than the DIP.
Pixel density: the pixel density of SMD is much more than DIP.

Q: What is a pixel and pixel pitch?
A: The pixel is the smallest unit of light-emitting, consists of red, green and blue colors. The same as ordinary computer monitors.Pixel pitch refers to the center of the distance between two adjacent pixels.

Q. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
