Product Detail
The P2.5 Indoor LED Display Screen from Leyarled is a 480×480 mm indoor LED display for reception walls, retail and wayfinding, built around a P2.5 screen that resolves 36,864 pixels per cabinet. Cabinets are sealed to IP40, run 1,000 cd/m² with 1920-3840 Hz refresh, and ship with the layout drawing, control configuration and spare modules already matched to the order.
P2.5 Indoor LED Display Screen: key features
- About 5.5 kg per cabinet, 217 W/m² average draw – a 1.92×1.44 m wall weighs roughly 15 kg and pulls 600 W.
- Epistar LEDs on a steel cabinet cabinet – both parts are held as spares in Shenzhen for five years after the order.
- Factory calibration before packing – each cabinet carries its own calibration file for field re-tuning.
- 36,864 pixels per cabinet (P2.5, 480×480 mm) – a 4×3 wall lands at 768×576 (0.44 MP) without any custom cutting.
P2.5 Indoor LED Display Screen technical specification
| Parameter | Value |
|---|---|
| Pixel pitch | P2.5 (2.5 mm) |
| Module size | 160×160 mm |
| Module count | 9 per cabinet |
| Cabinet size | 480×480 mm |
| Resolution per cabinet | 192×192 px (36,864) |
| Brightness | 1,000 cd/m² (auto dimming) |
| Refresh rate | 1920-3840 Hz |
| Scan mode | 1/16 |
| Protection | IP40 |
| LED lamp | Epistar |
| Cabinet material | steel cabinet |
| Cabinet weight | about 5.5 kg (24 kg/m²) |
| Average power | about 217 W/m² |
| Viewing distance | 3.8 m minimum, 8 m comfortable |
| Lifespan | 100,000 hours |
| Warranty | 3 years |
The table shows the standard build for this P2.5 Indoor LED Display Screen. Cabinet size, brightness and control system can be changed per project; the final datasheet is issued with the PI before production. Cabinets are tested against IEC 60068 for temperature, humidity and vibration.
How the numbers work on a real wall
The arithmetic behind this P2.5 Indoor LED Display Screen is simple enough to check before you order: 480÷2.5 = 192 pixels across each cabinet and 480÷2.5 = 192 down, so six cabinets in a row resolve 1,152 pixels at 2.88 m wide. Viewing distance follows the pitch – 3.8 m before the pixel structure disappears, 8 m before body copy reads cleanly. Because the cabinet divides into 9 standard 160×160 mm modules, a replacement module is never a custom order.
Product details
6, P2.5 LED display is of high resolution for indoor rental events that require high quality presentation and its cost is being lower for large size indoor LED screens use;
Where the P2.5 Indoor LED Display Screen is used
- Corporate offices – reception media walls and internal comms.
- Education – lecture theatres and campus wayfinding.
- Retail stores – promotional walls and window displays.
- Conference and hotel lobbies – welcome screens and event schedules.
Installation and service access
Indoor screens are typically wall-mounted on a bracket or recessed into a joinery frame. Because the viewing distance is short, we set brightness to 600-1200 nits and use a low-brightness calibration so the wall does not glare in a dim room.
A magnetic front-service module means the screen can sit flush against a finished wall. 3-year warranty on modules, power supplies and receiving cards; spare parts held in Shenzhen for five years after the order.
P2.5 Indoor LED Display Screen: frequently asked questions
Can you put our brand on the P2.5 Indoor LED Display Screen?
Yes. OEM branding covers the cabinet badge, the packing label and the manual, and the control software can be locked to your logo on request.
Will this P2.5 Indoor LED Display Screen survive a coastal or high-humidity site?
The cabinet is IP40 with a breathable pressure valve, and for coastal projects we add an anti-corrosion coating plus stainless fixings. Wash the front with a soft brush and deionised water every 6-12 months to keep salt off the mask.
What is the lead time for a P2.5 Indoor LED Display Screen order?
7-12 working days for standard P2.5 cabinets, 15-20 days if the order includes steel structure and on-site commissioning. Sea freight to most ports adds 18-35 days depending on the route.
How many spare modules should I keep?
Budget 2-3% of modules plus one power supply per 20 cabinets. A spare module is a five-minute swap, so the stock is insurance against downtime, not a repair plan.
Request a price for the P2.5 Indoor LED Display Screen
Send the screen size, viewing distance and project country, and our engineers return a layout drawing, a resolution map and a factory price within 24 hours. Similar models are listed under Indoor Full Color LED Display range, and you can compare p10 indoor led display screen, p4 indoor led display screen. Direct contact goes through the contact page. When you compare quotations, ask every supplier for the module brand, the power-supply brand and the spare ratio in the carton – that is where prices usually differ.
